45° Angled Grab Rail

Goldfern 45° Angled Grab Rail

The Goldfern 45° Angled Grab Rail provides a fixed diagonal handhold for bathrooms, showers and other areas where extra support is useful. The 45-degree layout gives the hand a choice of lower and higher gripping positions along the same rail, which can suit movements where the user's hand naturally changes height while sitting, standing or stepping.

MoveSmart offers the rail in Stainless Steel and antibacterial Nylon, with 310 x 310 mm and 600 x 600 mm options. Both finishes have a textured, water-resistant gripping surface, while the Nylon version adds an aluminium-reinforced core plus anti-UV and anti-aging surface properties. The range is NZS 4121 compliant.

Why Choose an Angled Grab Rail?

A straight horizontal rail gives support at one consistent height, while a vertical rail allows the hand to move up and down. An angled rail sits between the two, creating a continuous handhold that changes height along its length. This can make it a useful choice beside a bath, shower, toilet or other transfer area where the ideal hand position changes through the movement.

The best location and angle still depend on the person using the rail and the surrounding room. For accessibility or transfer installations, positioning should be considered together with reach, wall construction and the other fixtures in the space.

Stainless Steel or Nylon

The Stainless Steel version provides a clean, durable finish with a 32 mm grab circumference. The Nylon version has a slightly larger 35 mm circumference and a textured antibacterial outer surface over an aluminium-reinforced core.

Both options are designed for suitable wet and dry areas. The choice usually comes down to preferred feel, appearance, hygiene requirements and the installation environment.

Secure Installation Matters

A grab rail is only as useful as the structure it is fixed to. Installation should be completed using fixings appropriate for the wall construction and intended load, with secure structural support rather than relying on wall lining alone.

The Goldfern rail uses multiple fixing points at its mounting bases and is also compatible with the Goldfern Flat End for Grab Rails attachment where an adjacent-wall configuration requires it.

Key Features

• 45° angled design for a diagonal handhold.
• Stainless Steel or antibacterial Nylon finishes.
• 310 x 310 mm and 600 x 600 mm MoveSmart size options.
• Textured, water-resistant surface designed for grip.
• Nylon version has an aluminium-reinforced core.
• Nylon surface includes anti-UV and anti-aging properties.
• NZS 4121 compliant.
• Compatible with the Goldfern Flat End for Grab Rails attachment where appropriate.
• 12-month warranty.

Goldfern Grab Rail Care and Maintenance Guide

Frequently Asked Questions

What angle is the grab rail?

The rail uses a 45° angled design.

What finishes are available?

Current MoveSmart variants are available in Stainless Steel and antibacterial Nylon.

What sizes are available?

Current MoveSmart variants include 310 x 310 mm and 600 x 600 mm sizes in both finishes.

What is different about the Nylon version?

The Nylon version has an aluminium-reinforced core with an antibacterial surface that also includes anti-UV and anti-aging properties.

Is the surface suitable for wet areas?

The range has a water-resistant textured surface designed for grip in suitable wet and dry locations.

Does the rail comply with NZS 4121?

Yes. The Goldfern 45° Angled Grab Rail is NZS 4121 compliant.

Where can an angled rail be useful?

An angled rail may suit a location where the user's hand position changes in height during a movement, such as beside suitable bathing or transfer areas. The exact position should be determined for the user and installation.

Does it need professional installation?

Yes. Grab rails require secure structural fixing. Installation should be completed by a suitably qualified person using fixings appropriate for the wall construction and intended use.

Can it be fixed only to wall lining?

No assumption should be made that wall lining alone provides adequate support. The installer should confirm sound structural fixing and select the correct fixing method.

Can the Flat End accessory be used?

Yes. The Goldfern Flat End for Grab Rails attachment can be used where a suitable adjacent-wall installation requires it.

How do I select between the 310 and 600 mm sizes?

Choose according to the available wall area, intended hand position and installation layout. The rail should be positioned so it can be reached comfortably and used as intended.

How should I care for the rail?

Follow the Goldfern Grab Rail Care and Maintenance Guide linked above for cleaning and ongoing care.

What warranty is included?

The warranty is 12 months.

Can it be delivered across New Zealand?

Yes. Goldfern 45° Angled Grab Rails are available to ship NZ-wide from MoveSmart.
